₹ 167000 exc. gst
CAS-No.: 7681-49-4(Sodium fluoride)
NOTE: Shelf life is 6 months; it is recommended to use as soon as possible.
We also provides larger package size. Contact us for more information.
1. Characterizations
| Composition | Upconverting nanoparticles | |
| Diameter | 25 nm | |
| Appearance | Ivory white solution | |
| Crystal formula | NaYREF4(RE: Yb, Er, Tm, Gd, Mn, Lu) | |
| Concentration | 5 mg/mL | |
| Solvent | Water | |
| Dispersity of powder | Water or ethanol | |
| Excitation wavelength | 975 nm | |
| Sensitizer | Ytterbium (Yb3+) | |
| Activator | Emission wavelength | Fluorescence |
| Thulium (Tm3+) | 365/475 nm | Purple-Blue |
| Erbium (Er3+) | 545/660 nm | Green-Yellow |
| Thulium (Tm3+) | 804 nm | Near-infrared |
Fluorescence Image Upon Excitation at 975 nm of Upconverting Nanoparticles (reference only)
Upconversion Emission Spectra: a) 365/475nm, b) 545/660 nm, c) 804 nm of Upconverting Nanoparticles, excitation at 975 nm for reference only
TEM Image of Upconverting Nanoparticles
Typical Particle Size Distribution Image of Upconverting Nanoparticles From Dynamiclight Scattering Measurement
To check out the list of all products visit on https://yaavikmaterials.com/ quantum-dots-upconverting-nanoparticles /
To visit homepage click on https://yaavikmaterials.com/
The product is also available on https://www.yaavikmaterials.org/ , https://yaavikmaterials.in/
| Type | 365/475 nm (Purple-Blue), 545/660 nm (Green-Yellow), 804 nm (near IR) |
|---|---|
| Packaging | 10 mg |
